Automotive Wiring Harness

  • As the automotive industry continues to advance, electronic components increasingly require engineers to save space.
  • Additionally, electronic parts need to accommodate other modern car requirements. A wiring harness connects a car’s electronic parts.
  • Besides, it transmits signals throughout the vehicle. The role resembles that of the human blood vessels and nerves.
  • At CLOOM Tech, we customize and produce the best automotive products. Our efforts contribute significantly to the development of the global automotive industry.

Aluminum Harnesses

At CLOOM Tech, we take the requirement of weight reduction seriously.
In this regard, we comply with the latest automotive requirements of less fuel intake and safety.
We use strong aluminum wires in the engine products to minimize weight and other expenses.
Aluminum Harnesses

Properties

CLOOM Tech applies durable aluminum wires to manufacture automobile products. We no longer rely on copper and other standard aluminum wires.

Along with good strength, aluminum harnesses have high bending properties. That reduces the weight and expenses of auto products.

Technology

The bending and strength factors of the materials we use are twice those of conventional materials. That facilitates a proper weight decrease of the wires.

The properties will also allow you to use our products even in vibrating and winding engine parts.

Wiring Harness for Sliding Door

These products provide constant power to sliding doors. Besides, they transmit signals to and from the car body to the doors. CLOOM Tech’s sliding door products consist of autonomous flat cables. Apart from flexibility, our products have small sizes, less weight, and sections.

Properties

First, it follows a steady motion path (always slides in one direction).

Secondly, it fits even in narrow spaces within the doors.
Lastly, it reduces unnecessary noise.

Technology

We combine the cables and the spinning components to protect the moving tracks. Furthermore, this brings compatibility to the opening and closing of sliding door tracks.

EPB Harness Integrated with Wheel
Speed Sensor

We integrate a wheel velocity sensor and an EPB harness. It is important to note that the electrification of supplementary parts with EPB facilitates the technique.This reduces product weight and production expenses. Furthermore, the method reduces the unit price of products. Still, car manufacturers can save on installation costs.

Integrated EPB Wheel Speed Sensor Technology

We incorporate the wheel speed sensor and the EPB harness by joining two ABS cables with two EPB cables.

We reduce the working time of assembling parts and cars.

By streamlining the routing design for automobile companies, the technique reduces the weight of cars.

Integrated EPB Wheel Speed Sensor Properties

You can easily integrate multiple driver-assistance functions to counter service brake failure.

The exclusion of incompetent brake lever provides extra interior designing options.



Automotive cables — Automotive Jumper cable

Jumper cables, booster cables, or jumper leads are perfect for when you find yourself stranded on the side of a highway. You can be back on your way in five minutes with just these few simple steps!

Technology:

Cloom’s Battery Jumper Cables come in three sizes: 4 AWG, 2 AWG and 1/0 AWG (0 gauge) with lengths ranging from 10 to 20 feet. They are perfect for any kind of car that is on the go!

Made with UL listed cable, seamless tinned copper ring terminals and adhesive lined heat shrink, these heavy duty wires can withstand UV light as well as water and fungus for years to come.

Cloom’s heavy-duty clamps have a copper ribbon that connects both jaws so BOTH sides of the clamp provide power to the battery when starting.

Features:

The innovative design of these jumper cables makes them the best for starting large diesel trucks, heavy-duty fleet equipment like cars and semi-trucks.

Made with premium materials that are designed to last in even cold weather conditions!

Copper cables which are 100% pure come with adhesive lined, irradiated polyolefin (PO) heat shrink to keep water and fungus out. Additionally, the PO is exceptionally resistant against UV light for long-lasting protection.

Automotive cables — Automotive Battery Cables

Battery cables play an integral role in your vehicles entire electical system allowing you start-up function with ease.

Technology:

Cloom assembles various sized copper wires like 4 AWG, 2 AWG, 1/0AWG and 4/0 AWGs in order to suit any customer needs!

Cloom manufactures battery cables that are perfect for use with DC to AC power inverters and can be used in many other applications.

Features:

Our battery cable comes with either 5/16″ or 3/8″ ring terminal depending on how much current it can handle at once before overheating.

The Adhesive-Lined Irradiated Polyolefin (PO) heat shrink makes the cables more water resistant, fungus proof, and UV light resilient than ever before!

Automotive cables —Automotive Lift Cables

The cables responsible for making sure the swing arms are level and the vehicle is lifted evenly when raising or lowering a lift should be inspected monthly.

Technology:

We spend years of research and development with OEMs to create cables that not only meet their quality standards but exceed them.

The maintenance team performs frequent pull strength and breakage testing on our lift cables or equalization cables to ensure high-quality products.

We take pride in providing quality auto lift cable products with OE specifications or custom lengths made from high-quality materials at affordable prices.

Cloom offers a variety of cables for different lifts, so you can easily find the right one to suit your needs.

Features:

All cables are made in China and assembled in our manufacturing facility.

We use only the highest grade of 12L14 cold drawn steel in our parts because we know that it will withstand tough conditions and last longer than any other metal on earth, thanks to its long-lasting properties.

Stainless steel rope is the toughest material out there. You can’t beat it for extreme applications and anything that needs to be strong, durable, or long-lasting in order to stand up against heavy use.

Quality Assurance in Manufacturing

A wire harness is an essential product for car efficiency and safety. Even slight faults, such as a stereo failure, can irritate you. Moreover, significant failures, like driver-assistance system failure, can offset your vehicle’s efficiency and safety. Therefore, you need the quality assurance of such products. At CLOOM Tech, we acknowledge that low-quality products can be more than an inconvenience.

 It is a matter of life and death to us! That is why we customize and manufacture our products to precision. This guarantees our customers the best quality and safety.

CLOOM Tech products meet SAE and IPC/WHMA-A-620 quality standards. Additionally, our products are ISO compliant. For your information, CLOOM Tech is UL and CSA certified. Our manufacturing factory also complies with RoHS standards.

Still, for the safety of the environment, we practice green production processes in our daily activities. In particular, we champion the recycling of waste products.

Our Partnerships with Top Manufacturers
and Suppliers

CLOOM Tech has rich experience in wire harness manufacturing and supply. We boast of our outstanding reputation worldwide. Also, we consider flexibility and a professional approach as the pillars of our success.

We customize and manufacture our products according to client specifications. First, our engineers take time to understand customer vision and specifications for custom products. Then, they apply extensive research and their engineering knowledge to come up with innovative and low-cost solutions.

We partner with reputable suppliers to have an extensive, internal inventory of the best interconnect raw materials. Our collaborations further ensure that our clients get the highest quality products of their choice.

These are some of our partners who complement our manufacturing and supply efforts:

Custom Cable and Wire Harness
Assemblies

We provide full-cycle design and manufacturing services. On top of that, we offer extra value-added services that meet customer specifications. We produce nothing other than the best quality products. CLOOM Tech custom products can accommodate different wire numbers and colors.

Our manufacturing capacities are not limited to:

Crimping

Cutting

Cooling

Connecting

Sub-assembly integration

Ultrasonic wire welding.

Terminal use

Stripping

Soldering

Marking

Types of the automotive wiring harness

Lead Wire

The lead wire is convenient in joints with multiple connections. The presence of a single cable in a box makes it easier to make internal electrical connections.

AVSS Wire

AVSS wires are thin-walled, have many stranded conductors and bending properties. Besides, they are resistant to both fire and heat. That makes them withstand the adverse engine environment.

FLYY Wire

The FLYY can accommodate thin walls and low-voltage typical in the automotive industry.



Custom Automotive Wiring Harness Services

Wire markings play a significant role in minimizing labor throughout the assembly process. CLOOM Tech’s unlimited service teams strive to make the highest quality products. We provide product interaction from the beginning to the end. Additionally,

 our support team responds promptly to customer inquiries. Likewise, we complete engineering requirements within hours instead of several weeks and months. That allows your assembly and R&D to be ahead of schedule. Contact us today for the highest quality products.

Some of the services we provide include:

Quote response within one day

Product testing and visual inspection

Sketches provision

We support both small and large scale production

Customized cable codes and labels

Buying of connectors and wiring harness production

Applications of Automotive Wire Harness

Automobiles apply a wide range of wire harnesses for the highest possible performance. These wires combine the wiring of various electrical and electronic equipment into one system. The integration injects efficiency into a vehicle’s power and signals transmission system.

We customize and manufacture these products according to a customer’s electrical and geometrical needs. You can embed these wires into your car’s body, sliding doors, power windows, engine, and others.

Below are the common uses of these products:

Automotive and long trucks

Motorbike assembling.

Golf carts

Smaller trailer harness

ATV and Karts repair

Farm machinery and garden tools

Aircraft and planes

Are You Ready To Boost Your Sales With Our
Manufacture Solutions?

Get a quick quote now.

Automobile Wire Harness-Growing Demand in the Automotive World

From harsh environmental factors to numerous abrasions, automobile wire harness need to weather numerous storms. The automotive industry utilizes wire harnesses like no other. As electrical links connecting various components in an automobile, wire harnesses are indispensable to automobiles.
The range and quality of functionalities in modern vehicles are on the rise, and this is bound to expand the demand for wire harnesses in the industry. Most modern cars have integrated wire harnesses that are more sophisticated than standard wire harnesses.
In this dossier, we explore automobile wire harnesses from the inside out.

 CHAPTER 1: Automobile Wire Harness

Automobile Wire Harness01

What is an Automobile Wire Harness?

An automobile wire harness is an electrical cable assembly that facilitates the transmission of signals in electrical devices. It’s a well-structured unit bundle of conductive wires.

As such, it facilitates cross-connections and interactions between various electrical components of an automobile. Wire harnesses are integral parts of a vehicle’s electrical system.

The automobile industry’s demands for wire harnesses eclipse those of nearly every other industry. As such, the variety of wire harnesses deployed in the industry is more productive than those used in any other industry.

Automobile wire harnesses serve as transmission systems combining the wiring of various electrical and electronic components in a car. As such, they coordinate and empower the various functions of a car’s components.

They lend themselves to use in electrical and electronic systems of automobiles, including electrical circuitry. Hence, they can adapt to a wide variety of conditions and applications.

However, for them to do so, their material composition should choose with great care. The next chapter shows you the first wires that make up an automobile wire harness.

 CHAPTER 2: Primary Wire for Automobile Wire Harness

Automobile Wire Harness02

 Electric cables serve an uncounted number of purposes in the car industry. Every wire harness comes with a unique material composition that makes it best suited to a specific purpose.

Each automobile wire harness deals with a unique combination of environmental factors like heat, emissions, vibrations, and so on. Moreover, that’s all the more reason why their physical makeup requires conscientious selection.

The material composition of wire harnesses categorize into two:

The Insulating Materials

This material part of the wire harness serves up a layer of protection against heat, chemical compounds, and vibrations. It usually consists of various halogen-free polymer bases (PVC, chlorinated polymers, polypropylene, and so on.)

Usually, we select the insulation materials for a wire harness based on the purpose for which the harness is designed to serve.

Insulation materials best suited for resisting temperatures of varying degrees include polyesters classes ranging from T2 to T61. These insulation materials are usually the aptest for use in cables for batteries and electric vehicles.

Insulating materials best-suited to mitigating abrasions include polyesters of classes T3 and T4.

Conductor Materials

Conductor Materials

Copper is the most widely used conductor material for wire harnesses. When alloyed with magnesium, copper serves as a more reliable conductor and provides a lot more capabilities with a smaller diameter.

However, aluminum, being a much cheaper and lighter conductive material than copper, is also gaining full acceptance by the day. Due to its excellent thermal capacities, aluminum has been the most widely used conductor material for battery cables.

Moreover, now, its alloys are being put to use in an increasing number of applications. However, copper cables have the advantage of yielding greater capacities with smaller diameters, and therefore outperforms aluminum regarding flexibility.

And now, you know the most commonly used types of wires for an automobile wire harness. However, what types of wire harnesses can these materials be used to create?

 CHAPTER 3: Automobile Wire Harness Types

Automobile Wire Harness03

Standard Wiring Harness

This type of harness can be found in nearly every automobile. They’re usually plugged into the factory plug of a vehicle.

Hence, they can remain intact even after the successful installation of new devices like a radio. As a result, they allow you to install and uninstall different components more quickly and neatly.

Reverse Wiring Harness: This harness comes in a reverse setup of the standard wiring harness, plugging into the factory radio. With this harness, you’ll be able to restore your car’s factory radio plug when it gets damaged.

Hence a damaged factory radio plug cannot prevent you from installing an aftermarket radio.

Stereo Relocation Harness

In many vehicles, the radio connects and interacts with some other devices in the vehicle. With this relocation harness, you can efficiently manage and transfer your stock radio without disrupting other functionalities.

It also allows you to replace your stock radio with an aftermarket radio easily. It allows you to do so without disabling any of the car’s functionalities.

Amplifier Integration Harness

The factory amplifier uses an amplifier Integration harness to support the speakers or subwoofer. When you install an aftermarket radio, it’s the integration harness that helps you connect the new radio to the inbuilt speaker system.

Amplifier Bypass Harness

A vehicle with an inbuilt amplifier that supports your speakers or subwoofer also comes with a bypass harness. It helps you deactivate the inbuilt amplifiers to install an aftermarket amplifier.

With this harness, you can also replace the inbuilt amplifier with the aftermarket receiver’s inbuilt amplifier.

Chime Retention Harness

Chime Retention Harness

This harness powers the car’s inbuilt warning system that chimes to alert you of vehicle issues. Such issues range from lights that are mistakenly left on to an insufficient oil reserve, and more.

This alert system can be deactivated when you replace the stock radio with an aftermarket radio. However, with the chime retention harness, you can install a new radio without disabling the chime alert system.

Premium Harness

This harness powers the specialty services for a car. The premium harness system also empowers warning chimes as well as the factory amplifiers.

All these various types of wire harnesses can be confusing. However, to gain more clarity about them, you may need to prune the bunch of wires in the harness. That helps to remove unnecessary wires to make the wire harnesses neater and more manageable.
Want to learn about how to rid a wire harness of extraneous wires? The next chapter shows you the steps.

 CHAPTER 4: How to Remove a Wire from an Automobile Wire Harness

Automobile Wire Harness04

https://www.youtube.com/embed/6lewr9q2SCc

Many wire harnesses come with additional wires that make them look clumsy or unnecessarily bogus. It’s a common practice to cut and insulate extraneous wires in a wire harness.

However, the best way to deal with unused wires is to disconnect the external pins keeping the unused wires in place. You can also come in need of replacing the wire harnesses when they’re damaged or suffering from electrical issues.

There is a wide variety of tools for removing pins from various types of plugs. These tools simplify the removal of unwanted pins. Hence, they allow you to do the pin removal by yourself.

How to Remove Wires from an Electrical Harness

Open the hood and trace out the fuse block. The fuse block is usually found in the upper right corner of the engine compartment, close to the windshield.

Disconnect the fuse block from the center bolt holding it in place. After that, separate the fuse box from the transmission and chassis harness and the entire engine.

Trace out bolts placed sideways along with the windshield and remove these using a socket wrench. These bolts differ in lengths and sizes from one vehicle to another.

Moreover, in some vehicles, they’re replaced by the seam around the dashboard. In such cases, use a flat head screwdriver to rip open the seam around the dashboard carefully.

Next, remove the AC and ductwork by holding the tubing and severing it from the point where there’s a seam.

Two bolts run along the steering column around the wheel. Trace them out from underneath your dashboard, then remove them. Trace out all the other bolts fastening the dashboard, and remove them.

 Automobile Wire Harness

After that, take down the dashboard to reveal the wiring running through the back.

Turn to the firewall hole and run a fragile, strong thread between the firewall hole and the engine compartment. Knot the end of the thread and attach it tightly to the end of the fuse block to enable you to pull it to disconnect the wiring with greater ease.

To make it easier to reassemble the wires, take pictures of the wiring or write down how the color combination of the wiring. Alternatively, you can also mark each wire with regard to its position.

Next, disconnect every wire from the back of the wire harness, and then pull apart the fuse block from the point where it connects with the wire harness. You need to remove any bolts or rubber sheath around the wire harness if there are any. If you don’t do that, you’ll not be obliterating the harness.

Alternatively,you can insert a pin extractor in the plug’s open end where you have the pin you want to remove. Press down the barbs that are fastening the pin by pushing down the pin extractor. Hold the wires as tightly as possible around the back of the pin. With the barbs still pressed down, carefully pull out the wire together with the pin.

So far, you’ve learned about managing automobile harnesses and keeping them neat and crisp. However, Use neat harness what benefits? Find out in the next chapter.

 CHAPTER 5: Benefits and Applications of Automobile Wire Harness

Automobile Wire Harness05

Applications of automotive wire harnesses

There’s hardly any vehicle where you can’t find an automobile wire harness. some time’s you’ll most likely find an automobile wire harness in either the engine, body, or chassis of the vehicle.

You’ll find the body wiring harnesses in the dashboard, interior electrical components, power windows, boot and bonnet locks, and so on. You’ll also find body wiring harness as parts of the air conditioning system, connectors, and dimmer switches.

The engine wiring harness usually runs through cruise control systems, lock braking systems, and speed sensors. Other parts where you can find the engine wiring harnesses include the battery cables, engine fans, and ignition systems.

Moreover, the chassis wiring harnesses are usually comprised of the front, rear, and main harnesses.

However, each vehicle’s wire harness comes with a unique design that considers the electrical and geometrical peculiarities of the vehicle. For instance, heavy vehicles such as trucks and buses require different harnesses than those used in cars.

The Benefits of Automobile Wire Harnesses

Minimal Installation Time

With wire harnesses, you can install multiple wires in one go instead of installing a wire at a time. Not only does this help reduce installation time, but it also eliminates the possibility of errors.

When installing multiple wires prearranged in a single unit, the margin of error is reduced compared to attaching one wire per time.

Reduced Possibility of Short Circuits

An automobile wire harness combines multiple wires into a bundle unit. Therefore, there’s a lowered risk of short-circuiting in an automobile wire harness compared to loose wires.

Greater Resistance to Extreme Conditions

One of the most outstanding advantages of wire harnesses is their enhanced durability. Wire harnesses comprise highly durable materials that stand up to heavy use and massive power loads.

Better Fuel Efficiency

You can use an automobile wire harness to enhance the fuel efficiency of your vehicle.

Enhanced Performance of Hybrid Cars

Automobile wire harnesses enhance hybrid cars’ performance, even under extreme weather conditions, making hybrid cars more reliable.

They have excellent capacities to withstand heavy power loads, extreme thermal conditions, and lousy electromagnetic noise.

However, there are no guarantees that every automobile wire harness you’ll be acquiring will deliver all these benefits. It all depends on the quality of the harness, which leads us to automobile wire harness manufacturing.

 CHAPTER 6: Automobile Wire Harness Manufacturers

Automobile Wire Harness06

 The design and composition of an automobile wire harness depend on its intended function. The design and composition also depend on the type of vehicle that the harness will be used in. Manufacturers, therefore, produce wire harnesses based on customized specifications.

There’s, therefore, the need for excellent communication between the manufacturers and customers to minimize the possibilities of errors. It would help if you also kept close tabs on the manufacturer to ensure that they’re using only the best materials.

These materials must have excellent pliability and thermal capacities.

An excellent wire harness manufacturer tests harness at various phases of the production process. You need to check to ensure that the harness proves to comply with the latest industry standards in various tests.

Tips for Choosing the Best Automobile Wire Harness Manufacturer

Since there are numerous aspects to the fabrication of wire harnesses, you need to pay attention to many details. To help you avoid getting your wires crossed while choosing a manufacturer, here are some essential tips you should consider:

Emphasize on Excellent Communication

You can insist on frequent one-on-one meetings with the representatives of the company to avoid any misunderstanding. A company’s capacity to meet your requirements goes beyond its engineering and manufacturing prowess, encompassing communication skills.

Seek Out Testimonials and Reviews

It would help if you were sure that the company has sufficient experience in fabricating harnesses similar to yours. Moreover, the best way to determine that is to investigate their track records and previous projects.

Create Sketches

With a detailed sketch at hand, it’ll be easier for you to communicate your harness specifications to a manufacturer. It can also help to provide the manufacturer with any relevant paperwork.

It is also advisable to put down as much as you can concerning the purpose of your harness in a paper.

Check for the company’s credentials: Certifications are imperatives for the fabrication of electrical and electronic devices. It is due to the relatively higher safety and performance requirements in electronics.

Some certifications that you should look out for when choosing a wire harness manufacturer include CSA International, the UL Registration, and so on.

Consider the Environment Which Your Harness Will be Operating In

Environmental factors should be one of the main determinants of your automobile wire harness’s appropriate material and designs. These factors include sunlight, vibration, water, and so on.

The company must take the presence of these factors into account during the fabrication processes.

Inspect the Fabrication Plant

You need to ensure that the company has all the essential facilities. If the company outsources some parts of the fabrication processes, look into the arrangements and the parties involved.

 Conclusion

A faulty automobile harness can wreak havoc in numerous ways. Therefore, safety and reliance are two vital considerations that you must have in mind when looking to acquire an automobile wire harness.

We understand that there are many things to look out for when sourcing for a wire harness. Our production processes are designed to put you at ease, regardless of the unique requirements of your automobile harness.

We’re here to provide you with our automobile wire harness expertise whenever you’re ready for it.

Lets Cloom Suport Your Projects

Get A QUICK QUOTE

Fill in your details and we’ll get back to you in 24 Hours.

Get A QUICK QUOTE

Fill in your details and we’ll get back to you in 24 Hours.
